G1012 18" Bandsaw -43-
REF PART # DESCRIPTION REF PART # DESCRIPTION
001 P1012001 UPPER FRAME ARM
002 P1012002 LOCK KNOB
003 P1012003 SWITCH PLATE
004 P1012004 GUIDE POST
005 P1012005 SUPPORT BRACKET
7 ⁄
8
" I.D.
06A P1012006 THUMB SCREW 1 ⁄
4
"-20 X 3 ⁄
8
"
007 P1012007 GUIDE BLOCK HOLDER
008 P1012008 ROUND GUIDE BLOCK
009 PB51
HEX BOLT 1 ⁄
4
"-20 X 3 ⁄
8
"
010 PW06 FLAT WASHER 1 ⁄
4
"
011 PB05 HEX BOLT 1 ⁄
4
"-20 X 3 ⁄
4
"
012 P1012012 GUARD PLATE
013 P1012013 HEX SHAFT
014 P6200
BALL BEARING 6200
015 PR01M EXT RETAINING RING 10MM
016 P1019Z033 BLADE ADJUSTING SCREW
017 P1012017 UPR WHEEL SLIDING BRKT
018 P1012018 SPRING
019 P1019017 SQUARE NUT
3 ⁄
8
"-16
020 P1019018 ADJUSTMENT KNOB
021 PN02
HEX NUT 5 ⁄
16
"-18
022 PB51 HEX BOLT 1 ⁄
4
"-20 X 3 ⁄
8
"
024 P1019021 STEEL PIN
025 PRP16M
ROLL PIN 3 X 25
027 P6202 BALL BEARING 6202ZZ
028 P1012028 UPPER WHEEL
029 P1012029 WHEEL PROTECTOR
030 P1012030 UPPER WHEEL GUARD (IN)
031 P1012031 STUD
032 P1012032 UPPER WHEEL GUARD (O)
033 PB41
HEX BOLT 1 ⁄
2
"-12 X 1 1 ⁄
2
"
034 PW01 FLAT WASHER 1 ⁄
2
"
035 PN06 HEX NUT 1 ⁄
2
"-12
036 PR21M INT. RETAINING RING 35MM
037 PW06 FLAT WASHER 1 ⁄
4
"
038 P1012038 PIN
039 P1012039 HEX BOLT 5/8"-11 X 2
1 ⁄
2
"
040 PW14 FLAT WASHER 5 ⁄
8
"
041 P1012041 BASE
41A
P1012041A BEARING HOUSING
042 PN04 HEX NUT 5 ⁄
8
"-11
044 P1012044 TABLE INSERT
45A PRP44M
ROLL PIN 3 X 10
046 P1012046 TAPERED PIN
047 P1012047 TABLE
048 PB35
HEX BOLT 3 ⁄
8
"-16 X 2 1 ⁄
2
"
049 P1012049 TRUNNION CLAMP SHOE
050 P1012050 TRUNNION
051 P1012051 TRUN SUPPORT BRACKET
052 P1012052 LOCK KNOB FOR TABLE
52A
P1012052A COVER KNOB
053 P1012053 INDICATOR
054 P1012054 GAUGE
55A PB06
HEX BOLT 5 ⁄
16
"-16 X 2"
056 P1012056 HEX BOLT 3 ⁄
8
"-16
057 PN08 HEX NUT 3 ⁄
8
"-16
058 PW02 FLAT WASHER 3 ⁄
8
"
059 PB05 HEX BOLT 1 ⁄
4
"-20 X 3 ⁄
4
"
061 P1012061 LOWER SUPPORT BRACKET
062 PN01
HEX NUT 1 ⁄
2
"-20
063 P1012063 LOWER WHEEL SHAFT
064 P1012064 BLADE COVER
065 PK35M
KEY 5 X 5 X 20
066 P6205 BALL BEARING 6205
067 PR01M EXT RETAINING RING 25MM
068 P1012068 LOWER WHEEL
069 P1012069 SPECIAL LEFT-HAND NUT
070 P1012070 LARGE PULLEY
072 PVA32
V-BELT A-32
074 P1012074 PAN HEAD SCREW
