G1012 18" Bandsaw -9-
Hardware Bags
Inside Bags Qty
Carriage Bolts 5 ⁄
16
" - 18 x 1 ⁄
2
" 24
Flat Washers 5 ⁄
16
" 40
Nuts 5 ⁄
16
" - 18 32
Hex Head Bolts 5 ⁄
16
" - 18 x 3 ⁄
4
" 4
Hex Head Bolts 5 ⁄
16
"-18 x 1" 4
Hex Head Bolts 1 ⁄
2
" - 12 x 1 1 ⁄
2
" 4
Hex Nuts 1 ⁄
2
" - 12 4
Flat Washers 1 ⁄
2
" 8
Cap Screws 1 ⁄
4
"-20 x 1 1 ⁄
2
" 4
Phillip Hd Screws 1 ⁄
4
" - 20 x 1 ⁄
2
" 2
Hex Nuts 1 ⁄
4
" - 20 2
Flat Washers 1 ⁄
4
" 4
Setscrews 1 ⁄
4
" x 1 ⁄
4
" 2
Hex Bolts 3 ⁄
8
"-16 x 3 ⁄
4
" 2
Hex Bolts 3 ⁄
8
"-16 x 1 1 ⁄
4
" 2
Hex Nuts 3 ⁄
8
"-16 5
Flat Washers 3 ⁄
8
" 4
Lock Nuts 3 ⁄
8
" 4
Hex Bolt 3 ⁄
8
"-16 x 3" 1
Hex Bolt 5 ⁄
8
"-11 2
Flat Washers 5 ⁄
8
" 2
Fence Rail Spacers 4
5 x 5 x 20mm Key 1
Lock Knob (Male) 1
Star Knobs (Female) 2
Strain Relief w/Plastic Nut 1 ⁄
2
" 1
5mm Hex Wrench 1
3mm Hex Wrench 1
Adjustment Bolts (w/Eye) 2
Guide Blocks 8
Thumbscrews 1 ⁄
4
"-20 x 1 ⁄
2
" 8
Roll Pin 3 x 10mm 1
Table Insert 1
Rubber Feet 4
In the event that any non-proprietary parts are
missing (e.g. nuts or washers), we would be glad
to replace them, or for the sake of expediency,
replacements can be obtained at your local hard-
ware store.
Figure 3. Stand components.
Figure 4. Bandsaw components.
