Grizzly G5049Z - Manual (Page 24)

-22- G5049Z Combination Sander
REF PART # DESCRIPTION
71 P5049071 WASHER
72 P5049072 STRAIN RELIEF
73 P5049073 DUST COVER
74 P5049074 SNAP RING
75 P5049075 BEARING
76 P5049076 SNAP RING
77 P5049077 SPACER
78 P5049078 DRIVE DRUM
79 P5049079 SETSCREW
80 P5049080 BEARING
81 P5049081 SNAP RING
82 P5049082 IDLER DRUM
83 P5049083 IDLER SHAFT
84 P5049084 SLIDING BAR
85 P5049085 ROCKER PLATE
86 P5049086 LOCK WASHER
87 P5049087 CAP SCREW
88 P5049088 FENDER WASHER
89 P5049089 HEX BOLT
90 P5049090 HEX BOLT
91 P5049091 WASHER
92 P5049092 ECCENTRIC
93 P5049093 SPACER
94 P5049094 ROCKER ARM
95 P5049095 HEX NUT
96 P5049096 LEVER, SHORT
97 P5049097 LEVER, LONG
98 P5049098 KNOB
99 P5049099 JAM NUT
100 P5049100 KNOB
101 P5049101 PULLEY
102 P5049102 BRACKET
103 P5049103 BEARING BLOCK
104 P5049104 JACK SHAFT
105 P5049105 DRIVE DISC
106 P5049106 TIRE
107 P5049107 BLOCK
REF PART # DESCRIPTION
108 P5049108 CAP SCREW
109 P5049109 SPRING
110 P5049110 LOCK WASHER
111 P5049111 MOTOR
112 P5049112 MOUNTING BLOCK
113 P5049113 ARM
114 P5049114 THREADED SHAFT
115 P5049115 STUD
116 P5049116 BRACKET
117 P5049117 HEX BOLT
118 P5049118 WHEEL
119 P5049119 HUB, LEFT
120 P5049120 HUB, RIGHT
121 P5049121 SPECIAL NUT
122 P5049122 MOTOR BRACKET
123 P5049123 SCALE
124 P5049124 RIVET
125 P5049125 KEY
126 P5049126 SNAP RING
127 P5049127 HEX BOLT
128 P5049128 LOCK WASHER
129 P5049129 CAP SCREW
130 P5049130 KNOB
131 P5049131 SETSCREW
132 P5049132
SETSCREW
133 P5049133 SCREW
134 P5049134 HEX NUT
135 P5049135 ALLEN WRENCH
136 P5049136 CAP SCREW
137 P5049137 ROUND THING
138 P5049138 WASHER
139 P5049139 JAM NUT
142 P5049142 CHART
143 P5049143 POINTER
144 P5049144 SETSCREW
145 P5049145 WASHER
