-44-
g3622-23/g3708/g4787-88 industrial Buffer
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PN36 HEX NUT 1-1/4"-7 10 P4787010 MOTOR 3HP, 220V, 3-PH
2 P4787002 COMPLETE SPACER SET 11 PB06 HEX BOLT 5/16-18 X 2
2-1 P3623002-1 SPACER 1-1/4" X 1" 12 PW07 FLAT WASHER 5/16
2-2 P3623002-2 SPACER 1-1/4" X 1-1/2" 13 PLW01 LOCK WASHER 5/16
2-3 P3623002-3 SPACER 1-1/4" X 2" 14 PN02 HEX NUT 5/16"-18
3 PS06 PHLP HD SCR 10-24 X 3/8 15 G4789 STAND (OPTIONAL)
4 P4787004 SWITCH MS-11-3PV (3HP-3PH) 16 P6209 BALL BEARING 6209ZZ
5 PB07 HEX BOLT 5/16-18 X 3/4 18 P4787018 MACHINE ID LABEL
6 P4787006 SWITCH SUPPORT 19 P3622019 SAFETY WARNING LABELS
7 PB07 HEX BOLT 5/16-18 X 3/4 20 P3622020 ELECTRICITY LABEL 0.7W X 0.6H
8 P3623008 WRENCH 1-1/2" 21 P3708021 POWER CORD 12AWG x 4C
9 PN37 HEX NUT 1-1/4"-7 LH 22 G9987 SMALL GRIZZLY NAMEPLATE
9-1 PWR2 WRENCH 2"
G4787 parts List
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REpLAcE that label before using the machine again. contact
Grizzly at (800) 523-4777 or www.grizzly.com to order new labels.
