INSTALLATION WITH BASE
Place base rear-facing on vehicle seat.
(Refer to illustration on Page 7)
Thread vehicle lap belt through base belt Tabs
and buckle belt.
NOTE: Vehicle shoulder belt must NOT be
placed under belt Tabs.
Press down firmly on base to compress vehicle
seat cushion while tightening vehicle lap belt
(fig. a).
Pull front to back and left to right to check for
secure installation (fig. b). Vehicle lap belt
MUST stay tight.
If not secure, see “Vehicle Seat Belts” section.
Put car seat in base and pull up on car seat to
be sure it is locked in base.
Place child in car seat and check for secure
installation (see ).
Adjust handle to a position behind car seat.
1
3
4
5
2
7
8
6
Check level indicator on base.
Ball MUST be entirely in green zone (fig. c).
If necessary adjust Foot.
NOTE: Vehicle must be on level ground and
child in car seat when leveling.
