OPERATIONS and ADJUSTMENTS

(continued)

Adjusting or Changing Harness Straps (fig. c):

Harness straps must be through slots at or below
shoulders.

• Press Tab to release metal Rod and lift Rod

out of side Pockets.

• Slide metal Rod out of Loops of harness

straps.

• If necessary to change slots, pull harness

strap out of current Slots and thread through
desired Slots.

IMPORTANT: Straps MUST be through
matching Slots of seat pad and car seat.

• Adjust strap length by inserting metal Rod

into any Loop that will provide proper
snugness.

• Replace metal Rod into side Pockets and

slide Rod down below Tab.

Make sure Tab holds metal Rod secure

ly.

Changing Crotch Strap Positions (fig. d):

Buckle tongue must be in slot closest to but
not under child.

5-Point Models Only

• From bottom of car seat, remove crotch

strap Clip.

• From top of car seat, rethread crotch strap

through desired Opening.

• Re-attach crotch strap Clip exactly as

shown.

Pull on buckle to make sure it is held
securely
