GE GXFM04FBL - Manual

INCLUDED COMPONENTS
■ Faucet mount unit
■ Carbon block filter
■ Faucet adapters and gasket
TOOLS NEEDED
■ None
GE Faucet Mount Filter
USE AND CARE/INSTALLATION INSTRUCTIONS
Faucet Mount Filtration System—GXFM03C and GXFM04FBL
SAFETY PRECAUTIONS
■ Check with your local public works department for
plumbing codes. You must follow these guidelines as you
install the Water Filtration System.
■ Use the Water Filtration System on a potable, safe-to-drink,
home COLD water supply only. The filter cartridge will not
purify the water, or make it safe to drink.
■ Do not use on a hot water supply (100°F [37.7°C] max.).
■ Install or store where it will not be exposed to temperatures
below freezing or exposed to any type of weather. Water
freezing in the system will damage it.
■ Your Water Filtration System will withstand up to 100 pounds
per square inch (psi) water pressure. If your house water
supply pressure is higher than 100 psi, install a pressure
reducing valve before installing the Water Filtration System.
■ WARNING: Do not use with water that is microbiologically
unsafe or of unknown quality without adequate disinfection
before or after the system. Systems certified for cyst
reduction may be used on disinfected water that may
contain filterable cysts.
■
Discard all unused and packaging material after installation.
Small parts remaining after installation could be a choke
hazard.
GXFM03C and GXFM04FBL are Tested and Certified by NSF
International against NSF/ANSI Standard 42 for the reduction
of Particulate Class 1, Chlorine, Taste and Odor and NSF/ANSI
Standard 53 for Lindane, Atrazine, lead, cyst and turbidity.
Your new GE faucet mount filter comes complete with all the necessary hardware for most installations. Each filter gives you up to 3 months
of great tasting water. The filter should be changed after 3 months of use or 200 gallons, whichever comes first.
Service Service Temperature
Model flow rate Life Pressure Range
GXFM03C 0.6 gpm 200 gallons 30–100 psi 40°–100°F
GXFM04FBL (2.3 Lpm) (757 liters) (2.1–6.9 bar) (4.4°–37.7°C)
or 3 months
INSTALLATION
Wash hands. Remove the existing aerator
from the sink faucet. Do not discard gasket;
it may be necessary to use the existing gasket
for the installation of adapters.
Identify the type of threads on the faucet:
■ External threads – No adapters should be
required. Proceed to Step 3.
■ Internal threads – Use trial and error to
select the proper adapter and washer
combination. Screw adapter and gasket
onto faucet. Be careful not to cross thread
the adapter; tighten manually.
NOTE: Adapters and gaskets have been included to connect to
most faucets. To insure a leak-free seal, you may need to use your
existing gasket (removed during Step 1) from your faucet’s aerator
in addition to the gasket included with this system. If the adapters
will not connect to your faucet, it is recommended to consult a local
plumbing or hardware store for assistance in obtaining the correct
adapter for your faucet.
Connect the faucet mount filter to the faucet/adapter by turning
the collar to tighten onto the threads of the faucet/adapter.
Be careful not to cross thread the unit; tighten manually. It is not
recommended but if necessary, you may use pliers to assist
with installation.
Slowly turn on the cold water (about half open) and check
for leaks. Tighten as necessary. Enter filter installation date
on change filter reminder and place on calendar at 3 months
from install date.
With the cold water fully open, pull the valve stem to begin
flushing the system. Flush new filters for 10 minutes to remove
any harmless carbon fines that may be in the system. When the
water is shut off, the valve stem will automatically return to the
unfiltered position. 5
4
3
2
1
SPECIFICATION GUIDELINES
* Filter life varies with local water conditions.
Gasket
Aerator
Faucet adapters
and washers
GENERAL ELECTRIC COMPANY, Appliance Park, Louisville, KY 40225 215C1044P035 49-50204 04-06 JR
For service in the U.S., contact us at: ge.com or call 800.GE.CARES. 146327 Rev. E
In Canada, call toll free, 866.777.7627.
Use a damp cloth and mild soap for cleaning. Do not use harsh
chemicals, detergents, abrasives, solvents or cleaning fluids, since
they will damage the filtration system.
CLEANING THE SYSTEM
Valve
stem
Filtration system aerator
Swivel
collar
Valve
stem
Filtration system aerator
Swivel collar
GXFM04FBL GXFM03C
