Adjusting depth – Grizzly H6144 User Manual
Page 11

H6144 34° Angle Finish Nailer–2½"
-10
-
Figure 5. Depth adjustment knob.
Besides damaging your workpiece,
deflection can cause injury if your free
hand is securing the workpiece in the
location that the nail deflects.
5. Pull the trigger. If the nail drove into
the wood far enough, continue with
your intended operations. If the nail
went too far or not far enough, adjust
the depth adjustment knob shown in
Figure 5, in Adjusting Depth.
Figure 4. Example of nail deflection.
Adjusting Depth
The Model H6144 features a knurled
adjustment knob (
Figure 5) for setting
the nail depth into the workpiece.
