Machine data sheet – Grizzly 12" Parallelogram Jointer G0609 User Manual
Page 7
-4-
G0609 12" Parallelogram Jointer
Machine Data Sheet
MODEL G0609 12" PARALLELOGRAM JOINTER
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
MACHINE DATA
SHEET
Product Dimensions:
Weight .............................................................................................................................................................875 lbs.
Length/Width/Height .........................................................................................................................84" x 33" x 43
1
⁄
2
"
Foot Print (Length/Width) ............................................................................................................................44
1
⁄
4
" x 17"
Shipping Dimensions:
Type .......................................................................................................................................................... Wood Crate
Content ............................................................................................................................................................Machine
Weight ..........................................................................................................................................................1, 036 lbs.
Length/Width/Height .....................................................................................................................88
3
⁄
8
" x 29
3
⁄
4
" x 40
1
⁄
2
"
Electrical:
Switch ...................................................................................................... Magnetic with Thermal Overload Protection
Switch Voltage .....................................................................................................................................................220V
Recommended Breaker Size ........................................................................................................................... 20 amp
Plug ..........................................................................................................................................................................No
Motors:
Main
Type ................................................................................................................ TEFC Capacitor Start Induction
Horsepower ................................................................................................................................................ 3 HP
Voltage .......................................................................................................................................................220V
Prewired .....................................................................................................................................................220V
Phase ....................................................................................................................................................... Single
Amps .............................................................................................................................................................. 18
Speed ............................................................................................................................................... 3450 RPM
Cycle ........................................................................................................................................................ 60 Hz
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings ...................................................................................................................... Shielded and Lubricated
Main Specifications:
Construction
Table Construction ............................................................. Parallelogram Design, Precision Ground Cast Iron
Fence Assembly ..................................................................................................................................Cast Iron
Body Assembly ....................................................................................................................................Cast Iron
Stand ....................................................................................................................................................Cast Iron
Guard. ................................................................................................................................. Moulded Aluminum
