ACCESSORIES
10
SQUARE TO ROUND CONVERTER
(DOWNFLOW APPLICATIONS)
A
B
R
S
C
D
16
ш
16
ш
18
ш
18
ш
22 3/4
22 1/4
12 1/4
14 3/4
12 1/4
14 3/4
22 3/4
22 1/4
MODEL
A
B
C
D
RETURN
SUPPLY
SQRPG101/102
22 3/4
12 1/4
22 1/4
14 3/4
16
16
SQRPG103
22 3/4
12 1/4
22 1/4
14 3/4
18
18
A
C
B
SQUARE TO ROUND CONVERTER
(HORIZONTAL APPLICATIONS)
Measurements are in inches.
*PH15[24-60]M4*
MODEL
A
B
C
SQRPGH101/102
16
16 1/2
16 1/2
SQRPGH103
18
18 1/2
18 1/2
