F. parts list – motor diagram e. motor diagram – Grizzly G1778 User Manual
Page 20
- 17 -
Ref. # Part #
Description
Ref. # Part #
Description
201
202
203
204
205
206
207
208
209
210
211
212
213
P1778201
Motor
P1778202
Switch Half
P1778203
Switch
P1778204
O-Ring
P1778205
Screw M3.5-0.6x13mm
P1778206
Wire Clamp
P1778207
Strain Relief
P1778208
Screw M4.5-0.75x13mm
P1778109
Cord
P1778110
Capacitor
P1778111
Switch Cover
P1778212
Handle
P1778213
Grease Gun
F. PARTS LIST – MOTOR DIAGRAM
E. MOTOR DIAGRAM
