Grizzly Press Table H7827 - Manual (Page 2)

13
12
11
10
4
16
10
14
7
2 6
3
5
1
8
17
REF PART # DESCRIPTION
1 PH7827001 T-TRACK
2 PH7827002 FENCE
3 PH7827003 STOP BLOCK
4 PH7827004 TABLE
5 PH7827005 KNOB M8-1.25
6 PH7827006 T-SLOT BOLT M8-1.25 X 35
7 PH7827007 T-SLOT BOLT M8-1.25 X 75
8 PH7827008 THREADED FLANGE
10 PH7827010 FLAT HEAD SCR 9/64" X 7/16"
11 PH7827011 STUD
12 PH7827012 HOLDDOWN
13 PW01M FLAT WASHER 8MM
14 PH7827014 INSERT BLOCK
16 PH7827006 TAPE SCALE
17 PH7827007 SADDLE
Parts
Accessories
g1514/g1515—Mortising Attachment
A.great.accessory.for.a.drill.press.is.the.mortis-
ing.attachment.for.drilling.square.holes.in.wood..
The.attachment.holds.a.variety.of.chisels..While.
the.drill.chuck.turns.the.bit.and.cuts.out.the.inner.
center,.the.square.chisel.reams.out.a.square.
hole..When.used.with.then.Model.H8727.Drill.
Press.Table,.the.mortising.attachment.mounted.
to.the.table.will.be.a.backup.accessory.that.can.
be.used.for.small.workpieces.
g1514.For.drill.press.collars.1 5 ⁄
8
".(41.3mm).dia.
g1515.For.drill.press.collars.1 7 ⁄
8
".(47.6mm).dia.
g9716.Adapter.for.g7947.&.g7948.drill.presses
Figure 3..g1514/g1515.Mortising.Attachment.
Maintenance and Care
Keep. •. your. cast. iron. drill. table. and. column.
rust. free. with. regular. applications. of. prod-
ucts. like. g96®. gun. Treatment,. SlIPIT®,. or.
Boeshield®.T-9.
To. avoid. condensation. and. rust. between. the. •.
two. tables,. do. not. leave. the. Model. H8727.
table.mounted.on.the.drill.press.table.for.long.
periods.of.time.
Clean. the. Model. H8727. drill. press. table. by. •.
vacuuming.out.T-slots.when.finished.and.wip-
ing. down. the. table. and. fence. with. any. good.
household. glass. cleaner.. Periodically. lightly.
oil.the.hand.knob.threads.and.the.studs.
Operation
Periodically. verify. the. mounting. clamps. are. •.
snug,.and.never.overtighten.the.hand.knobs.
To.avoid.drilling.into.the.table,.make.sure.that. •.
the.drill.press.depth.stop.and.drill.bit.alignment.
is.correct.
use.the.table.only.in.dry.environments. •.
Wipe.down.workpieces.to.ensure.they.are.free. •.
of.debris.that.may.scratch.the.table.
