G8690 Variable Speed Wood Lathe -9-
SECTION 4: ASSEMBLY
Beginning Assembly
Most of your Model G8690 has been assembled
at the factory, but some parts must be assembled
or installed after delivery. We have organized the
assembly process into steps. Please follow along
in the order presented here.
TOOLS REQUIRED: A metric socket set, 6"
adjustable wrench, and Phillips ® head screw dri-
ver.
Guide Rails
Figure 2. Guide rails installed.
Install the two guide rails between the two foot
assemblies and secure in place using the four
setscrews (M6-1 x 10) as shown in
Figure 2. .
Wear safety glasses
during the entire assem-
bly process. Failure to
comply may result in
serious personal injury.
Keep loose clothing
rolled up and out of the
way of machinery and
keep hair pulled back.
Disconnect power to the
machine when perform-
ing any maintenance,
assembly or adjust-
ments. Failure to do this
may result in serious
personal injury.
