Radial Engineering Ltd. Workhorse User Guide
2
REAR P
ANEL
FEA
TURE SET
MAIN OUTPUTS:
Jensen
transformer isolated to eliminate noise and add warmth. Equipped with
TRS
insert jacks for ef
fects.
MONIT
OR OUTPUTS:
Used
to send signal to your nearfi
eld
monitors with choice of XLR and 1/4”
TRS jacks. Features
independent level control.
STEREO LINK:
Makes it easy
to pair up modules equipped with a stereo link function in standard
API master slave
confi
guration.
FEED FUNCTION:
Lets you
connect one module into the next to set up elaborate channel strips without having to hard patch with cables.
CARD SLOT CONNECT
ORS:
Follows original XLR I/O format and adds parallel 1/4”
TRS jacks for easy
connectivity to workstations.
OMNIPORT™:
1/4” TRS
connector add functionality to enhance each module’
s
capability as set by the manufacturer
.
BALANCED 25-PIN D-SUBS: Eight channel D-Subs follow ProT
ools standard for easy
connectivity to workstations. Wired in parallel to XLR inputs and outputs.
SUMMING MIXER:
Built-in
eight channel summing mixer lets you mix ‘outside the box’ in the analogue domain for added warmth and character
.
EXP
ANSION BUSS:
Expand
the workhorse to 16x2 or larger by connecting one W
orkhorse into another
.
Simple 1/4” connections makes it easy
.
STUDIO GROUNDING: External grounding lugs makes it easy to set up star grounding schemes for high- end studio wiring.
EXTERNAL
POWER:
High
current external switching supply delivers 1600mA
to
the W
orkhorse plus separate
48V phantom feed for mic preamps.
