1
EIGHT CARD SLOTS:
Up to
eight 500 series compatible modules may be loaded into the W
orkhorse and connected
via standard card edge receptacle.
MIXER SECTION:
Ultra quiet
built-in mixer lets you tap signals from each module and mix them to the main, monitor or headphones.
LED INDICA
T
ORS:
Provide
visual power status for the +/- 16 volt module rails and 48V phantom power
.
DUAL
HEADPHONES:
Super
high output dual headphone amp with level control to ensure you can mix in any environment. Mono check switch.
STEEL
CASE:
The
W
orkhorse chassis is made
from heavy steel to provide extra shielding against stray magnetic fi
elds and RF
.
MIXER CHANNEL
INPUTS:
Each W
o
rkhorse channel is
equipped with volume control, left-right pan, LED overload indicator and channel on-of
f
for muting.
OUTPUT SECTION:
Separate
stereo controls for main, monitors and headphones make it easy to adjust levels or mute signals when needed.
EASY
-GLIDE TRA
Y
: Slide-in
platform for modules makes connecting to back plane easy by properly aligning card edge height.
DEEP
CURRENT POOL:
Modules can draw as much current as they need from a shared pool. Up to 1200mA total current is available.
FITS
ALL
MODULE SIZES:
Both single and double wide modules will fi
t in the
W
orkhorse. Removable tray
for non-standard modules.
FRONT P
ANEL
FEA
TURE SET
