Identification – Grizzly G4030 User Manual
Page 8
-6-
G4030 6
1
⁄
2
" x 10" Metal-Cutting Bandsaw
Identification
A. Blade Tension Knob
B. Guide Post Adjustment Knob
C. Blade
D. Coolant Nozzle
E.
3
⁄
4
HP Motor
F. Wheels
G. Feed Rate ON/OFF Valve
H. Bandsaw Cabinet
Figure 1. Main view of machine features.
A
B
L
N
O
G
I
F
E
D
C
I.
Workstop
J. ON/OFF Switch for Coolant Nozzle
K. ON/OFF Switch
L. Vise Handwheel
M. Vise
N. Blade Guides
O. Blade Tracking Controls
P. Gear
Shift
Lever
K
M
H
P
J
