Grizzly G4030 - Manual (Page 40)

-38- G4030 6 1 ⁄
2
" x 10" Metal-Cutting Bandsaw
Parts List G4030
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P4030001 VALVE COCK SUPPORT 50 P4030050 INTERVAL RING
2 PLW01 LOCK WASHER 5/16 51 P6202 BALL BEARING 6202ZZ
3 PSS21M SET SCREW M8-1.25 X 25 52 P4030052 BLADE WHEEL (FRONT)
4 PN08 HEX NUT 3/8-16 53 PLW04M LOCK WASHER 8MM
5 PLW04 LOCK WASHER 3/8 54 PB87M HEX BOLT M8-1.25 X 15
6 P4030006 BLADE ADJUSTER (FRONT) 55 P4030055 ADJUSTING KNOB 1/4
7 P4030007 PIN 56 P4030056 BLADE BACK COVER
8 P4030008 ECCENTRIC SHAFT 57 PSB04 CAP SCREW 1/4-20 X 1/2
9 P608 BALL BEARING 608ZZ 58 P4030058 BRUSH HOLDER
10 PR36M EXT RETAINING RING 7MM 59 PHTEK23 TAP SCREW #10 X 1/2
11 PSB03M CAP SCREW M5-.8 X 8 60 P4030060 BRUSH
12 P4030012 BLADE COVER (FRONT) 61 PB19 HEX BOLT 1/4-20 X 1/2
13 P4030013 WATER NOZZLE 62 P4030062 BLADE
14 P4030014 VALVE 1/4 63 P4030063 COMPLETE GEAR BOX W/ MOTOR
15 PS06 PHLP HD SCR 10-24 X 3/8 63-01 P4030063-01 PAN HD SCREW M5-.8 X 145
16 P4030016 HOSE BUTTON 63-02 P4030063-02 MOTOR WITHOUT GEAR BOX
17 P4030017 HOSE PLUG 1/4 63-02-2 P4030063-02-2 MOTOR FAN COVER
18 P4030018 HOSE 63-02-3 P4030063-02-3 FAN
19 P4030019 ADJUSTING KNOB 3/8 63-02-4 P4030063-02-4 CAPACITOR 300MFD 250VAC
20 PW02 FLAT WASHER 3/8 63-02-5 P4030063-02-5 CAPACITOR COVER
21 P4030021 ADJUSTABLE BRACKET (FRONT) 63-02-6 P4030063-02-6 JUNCTION BOX
22 P4030022 HEADSTOCK 63-03 PK53M KEY 3 X 3 X 45
23 PSS06M SET SCREW M8-1.25 X 16 63-04 P4030063-04 OIL SEAL
24 PB15M HEX BOLT M8-1.25 X 40 63-05 P4030063-05 WORM SHAFT
25 PLW04M LOCK WASHER 8MM 63-06 PSS02M SET SCREW M6-1 X 6
26 PB15M HEX BOLT M8-1.25 X 40 63-07 P4030063-07 GEAR BOX
27 PW03M FLAT WASHER 6MM 63-08 PSS20M SET SCREW M8-1.25 X 8
28 P4030028 SLIDE 63-09 P4030063-09 HANDLE
29 P4030029 BLADE TENSION SLIDING BLOCK 63-09-1 P4030063-09-1 COMPLETE HANDLE ASSY
30 PB16 HEX BOLT 3/8-16 X 1 1/2 63-10 P4030063-10 VARIABLE SPEED PIN HEAD
31 PLW06M LOCK WASHER 10MM 63-11 P4030063-11 SPRING N/S .8 X .5 X 25
32 PW02 FLAT WASHER 3/8 63-12 P4030063-12 VARIABLE SPEED PIN
33 P4030033 ADJUSTABLE BRACKET (REAR) 63-13 PW04M FLAT WASHER 10MM
34 P4030034 BLADE ADJUSTER (REAR) 63-14 PR01M EXT RETAINING RING 10MM
35 PW01M FLAT WASHER 8MM 63-15 P4030063-15 VARIABLE SPEED SHAFT
36 P4030036 DEFLECTOR PLATE 63-16 P4030063-16 O-RING
37 PFH03 FLAT HD SCR 1/4-20 X 1/2 63-17 P4030063-17 SWING LEVER BOLT
38 P4030038 TABLE 63-18 P4030063-18 SWING LEVER
39 PW01M FLAT WASHER 8MM 63-19 PW03M FLAT WASHER 6MM
40 PLW04M LOCK WASHER 8MM 63-20 P4030063-20 SWING LEVER BOLT
41 PB07M HEX BOLT M8-1.25 X 25 63-21 P4030063-21 OIL PLUG
42 P4030042 BLADE WHEEL (REAR) 63-22 P4030063-22 OIL SEAL
43 PR58M EXT RETAINING RING 24MM 63-23 P6205 BALL BEARING 6205ZZ
44 PB17M HEX BOLT M8-1.25 X 10 63-24 P4030063-24 SHAFT LOCK RING
45 PW06 FLAT WASHER 1/4 63-25 P4030063-25 MAIN SHAFT
46 P4030046 SWITCH HIP 63-26 P4030063-26 SHAFT KEY
47 PW02 FLAT WASHER 3/8 63-27 P4030063-27 BUSHING
48 P4030048 BLADE TENSION KNOB 63-28 PK38M KEY 4 X 4 X 22
48-01 P4030048-01 SPRING 1.8 X 14 X 102 63-29 P4030063-29 #1 GEAR
49 P4030049 BLADE WHEEL SHAFT (FRONT) 63-30 P4030063-30 #2 GEAR
