308–507
9
PARTS LIST
800–412 5:1 Monark (Cart Mounted) Hydra–Clean
r
Pressure Washer
REF PART
NO.
NO.
DESCRIPTION
QTY
1
224–044 CART (see instruction
manual 308–136)
1
2
801–112 STRAINER, Garden Hose
1
3
801–110 ADAPTER, Garden Hose
1
4
801–111 NUT, Garden Hose
1
5
800–113 FILTER
1
6
100–896 BUSHING, Hex 3/4 X 1/2
2
7
176–393 ELBOW, Street 3/4 X 90_
1
8
803–473 INJECTOR, Chemical
1
9
150–287 ADAPTER, Reducing 3/8 X 1/4 1
10
801–090 QUICK COUPLER, Male 1/4
2
11
800–374 HOSE ASSEMBLY, w/Quick
Couplers (incl. 10,21,22)
1
12
800–417 GUN AND WAND ASSEMBLY
(incl. 22,23,24,25,26,27,28 ) 1
13
801–683 STRAINER, Chemical
1
14
803–059 TUBING, Chemical 5/16 ID
8 ft
15
207–278 ACCUMULATOR (see
instruction manual 306–933) 1
16
803–446 FITTING, Swivel 1/2 X 1/2
1
17
202–156 REGULATOR ASSEMBLY (see
instruction manual 307–204) 1
18
208–393 VALVE, Ball 3/8 x 3/8 (see
instruction manual 307–068) 1
19
802–048 TIP, Spray 15 Degree
1
20
208–470 PUMP, 5:1 Monark
(see instruction manuals
306–800, 307–043)
1
21
801–007 HOSE, High Pressure 50’
1
22
801–009 QUICK COUPLER, Female 1/4
(incl. 28)
2
23
801–103 NIPPLE, Hex 3/8 X 1/4
1
24
208–008 GUN, Spray (see instruction
manual 307–010)
1
25
801–935 WAND, 20”
1
26
801–957 SLEEVE, 18”
1
27
800–118 NOZZLE, Adjustable
1
28
801–202 O–RING, Quick Coupler,
female 1/4
2
