308–507
11
PARTS LIST
800–413 10:1 President (Cart Mounted) Hydra–Clean
r
Pressure Washer
REF PART
NO.
NO.
DESCRIPTION
QTY
1
224–044 CART (see instruction
manual 308–136)
1
2
801–112 STRAINER, Garden Hose
1
3
801–110 ADAPTER, Garden Hose
1
4
801–111 NUT, Garden Hose
1
5
800–113 FILTER
1
6
100–896 BUSHING, Hex 3/4 X 1/2
2
7
176–393 ELBOW, Street 3/4 X 90_
1
8
202–156 REGULATOR ASSEMBLY
3/8 X 3/8 (see instruction
manual 307–204)
1
9
208–393 VALVE, Ball 3/8 X 3/8 (see
instruction manual 307–068) 1
10
155–899 ELBOW, Street 3/8 X 90_
2
11
801–700 TIP, Spray 15 Degree
1
12
800–396 GUN & WAND ASSEMBLY
(incl.19,25,26,27,28,29)
1
13
800–374 HOSE ASSEMBLY W/QUICK
COUPLERS (incl. 16,19,21)
1
14
100–081 BUSHING, Hex 3/8 X 1/2
1
15
206–842 PUMP, 10:1 President
(see instruction manuals
306–816, 306–982)
1
16
801–007 HOSE, High Pressure 50 ft
1
17
207–278 ACCUMULATOR (see
instruction manual 306–933) 1
18
803–473 INJECTOR, Chemical
1
19
801–009 QUICK COUPLER,
Female 1/4 (incl. 24)
2
20
150–287 ADAPTER, Reducing 3/8 X 1/4 1
21
801–090 QUICK COUPLER, Male 1/4
1
22
803–059 TUBING, Chemical 5/16 ID
8 ft
23
801–683 STRAINER, Chemical
1
24
801–202 O–RING, Quick Coupler,
female 1/4
2
25
801–103 NIPPLE, Hex 3/8 X 1/4
1
26
803–350 GUN, Spray (see instruction
manual 308–511)
1
27
801–935 WAND, 20”
1
28
801–957 SLEEVE, 18”
1
29
800–118 NOZZLE, Adjustable
1
