GateWay Fax Systems 90SI - Manual (Page 24)

GateWay Fax Systems, inc. Model 90si Secure Fax Gateway User's Guide
www.gwfs.com, 877-951-9800, [email protected] help line: 877-951-9814 page 24
90si Digital Interface Pin-Assignments
Pin # ID Description Direction
1 FG Frame Ground (sheild)
2 TD Transmit Data Output
3 RD Receive Data Input
4 RTS Request To Send Output
5 CTS Clear To Send Input
6 DSR Data Set Ready Input
7 SG Signal Ground
15 TC Transmit Clock Input
17 RC Receive Clock Input
20 DTR Data Terminal Ready Output
7.0 Related Web Links
We have provided a few useful weblinks below:
Model 90si Secure Fax Gateway: http://www.gwfs.com/90si.html
90si Presentations and Images: http://www.gwfs.com/90si/more.html
90si Choices: http://www.gwfs.com/Choices/90sichoices.html
90si User’s Guide in PDF format: http://www.gwfs.com/Header/TechnicalHelp/90siusers.pdf
Model 690 Mid-Volume Secure-Fax System: http://www.gwfs.com/690.html
Model 390 Low-Volume Secure-Fax System: http://www.gwfs.com/390.html
Company Information: http://www.gwfs.com/Footer/Moved.html
Technical Help: http://www.gwfs.com/Header/TechnicalHelp/help.html
Complete Price List: http://www.gwfs.com/Header/order.html
Product Selection Chart: http://www.gwfs.com/Header/chart.html
Frequently Asked Questions: http://www.gwfs.com/Header/faq.html
DISA/JITC Certification: http://www.gwfs.com/JITCCertification/JITCcert.html
Gov’t SecurePhone Website: https://www.iad.gov/securephone/index.cfm
GD Sectera: http://www.gdc4s.com/content/detail.cfm?item=87249ff2-22ae-
478f-a483-a475b5dd0a8d
GD vIPer: http://www.gdc4s.com/content/detail.cfm?item=0f71db22-0eb9-
413d-b144-8eea7c767e64
L-3 Omni: http://www.l-3com.com/cs-east/ia/omni/ie_ia_omni.shtml
L-3 STE: http://www.l-3com.com/cs-east/ia/ste/ie_ia_ste.shtml
8.0 Safety Information and FCC Requirements
Important Safety Instructions:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
