52
17.0 Securing Child in Vehicle with Shoulder Belt
Positioning Clip
™
The shoulder belt MUST lie across child’s
shoulders in red zone as shown ™.
If shoulder belt lies outside this zone, the
shoulder belt positioning clip MUST be used.
To attach clip to booster seat:
1. Insert the loop end of strap through the slot
on rear of seat exactly where shown š.
There is a slot on each side of booster seat,
the shoulder belt positioning clip MUST be
attached through the slot closest to where the
vehicle shoulder belt lies across the child.
š
