7.1 Harness Removal
1. Remove harness straps
from metal junction
plate. See figure 5 on
page 19 for more help.
Pull the straps through
harness slots. Do not
remove buckles or
harness clip from
straps Î .
Push straps, buckles
and harness clip through
bottom of seat.
2. Remove crotch strap.
See figure 3 on page 19
for more help.
Buckle crotch strap to
harness and fasten
harness clip together
for storage.
3. Metal junction plate
and strap are not
removable. Push in red
adjustment button and
pull strap to rear of seat
Ï . Snap junction plate
in back of seat
Ð
.
4. Store LATCH. See
Section 8.2, Storing
LATCH, page 32.
5. Reverse instructions to
reinstall. See figure 1 on
page 38 for the correct
path for the harness.
