Extreme Duty Planers
G9740/G9740Z
Disconnect power from machine
before performing any electrical
service. Failure to do this will result
in a shock hazard leading to injury
or death.
BLACK
BROWN
BLUE
BLACK
BROWN
BLUE
4
5
6
1
2
3
7
8
9
BLACK
BROWN
BLUE
220V
4
5
6
1
2
3
7
8
9
BLACK
BROWN
BLUE
440V
4
5
6
1
2
3
7
8
9
220V
4
5
6
1
2
3
7
8
9
440V
TABLE
MOTOR
FEED
ROLLER
MOTOR
CUTTER
HEAD
MOTOR
Motors
Voltage Conversion
220 Volt 3-Phase
