9
7. Attach the Left Upper Body Arm (22) to the left
Upper Body Leg (24) with three M8 x 15mm
Patch Screws (106).
Attach the Right Upper Body Arm (23) in the
same way.
6. While another person holds the Upright (10)
near the Frame (1), connect the ends of the
Upper Wire Harness (65) to the ends of the
Lower Wire Harness (64).
Tip: Avoid pinching the wires. Carefully insert
the Upright (10) into the Frame (1). Attach the
Upright with four M8 x 20mm Patch Screws
(107) and four M8 Split Washers (101).
22
23
24
106
7
6
65
64
107
101
101
1
10
Avoid pinching
the wires
107
