1. Installation
PNEG-301 Two-Ring Door 7
Parts List for Two-Ring Doors
KEY
PART #
DESCRIPTION
QTY
12'-27' and 30'-60' BIN DIAMETER
12'-27' and 30'-60'
BIN DIAMETER
2.66" and 4.00" CORR.
1 WD-039 OUTER DOOR COVER 1
2 WD-2854 OUTER COVER LATCH BRACKET 2
3 WD-225 OUTER COVER HINGE BRACKET 2
4 WD-035 DOOR COVER BRACE SECTION 4
5 WD-033 DOOR RETAINER 3
6 WD-6124 OUTER COVER LATCH MOUNT BASE 2
7 WD-6066 OUTER COVER HINGE BASE 2
8 WD-6055 BOTTOM INNER DOOR HINGE 1
9 WD-6056 MIDDLE INNER DOOR HINGE 2
10 WD-6054 TOP INNER DOOR HINGE 1
11 S-4380 RUBBER TRIM SEAL STRIP 2-1/4 FT.
12 WD-6039 LATCH BAR 3
13 WD-6037 INNER PANEL LATCH - RIGHT HAND 3
14 WD-6038 INNER PANEL LATCH - LEFT HAND 3
15 WD-6040 LATCH BUSHING 6
16 S-8648 1/2" X 1-1/2" HEX SOCKET CAPSCREW 6
17 WD-6079 LONG BEARING PIN 38
18 WD-6125 INNER PANEL REINFORCING ANGLE 6
19 WD-6128 BOTTOM INNER DOOR PANEL 1
20 WD-6127 MIDDLE INNER DOOR PANEL 1
21 WD-6126 TOP INNER DOOR PANEL 1
22 WD-6028 BOTTOM INNER DOOR PORT HOLE COVER 1
23 WD-6053 INNER DOOR HINGE STRAP 6
24 WD-1302 DOOR HOLD BACK BRACKET 1
25 WD-6110 DOOR HOLD BACK EXTENSION 1
