8
INSTALLING THE COOKTOP
PROTECT SURFACE OF COOKTOP
Place a towel or tablecloth onto the countertop.
Lay the cooktop upside down onto the protected
surface.
1 ATTACH FOAM TAPE
Apply the foam tape around the outer edge of the
glass. Do not overlap the foam tape.
NOTE: On stainless steel models, apply foam tape
on the sides and rear.
3
Bottom of Cooktop
Cloth under Cooktop
Bottom of Cooktop
Foam Tape
Cooktop
Glass
Installation Instructions
INSTALL HOLD-DOWN BRACKETS
Start one screw through the bracket and into the
cooktop. (Both sides.) Do not tighten. Turn the
bracket inwards to avoid interference when
dropping the cooktop into the countertop.
4 INSTALL BAFFLE
Secure the baffle to the cooktop with screws.
NOTE: Do not install the baffle when the cooktop
is installed over a single oven.
2
