- 8 - GV-R487D5-1GD Graphics Accelerator
How to enable the ATI CrossFireX TM technology?
Step 1:
Install two CrossFireX graphics cards of the same chipset on a CrossFireX-supported motherboard
(Figure 1). Then users can enable the CrossFireX technology through the graphics card driver.
Figure 1
Step 2:
After installing graphics card driver in operating system, when an ATI CrossFireX configuration is
detected for the first time by the ATI Catalyst display driver, ATI CrossFireX support is automatically
enabled, and the best possible GPU combination is selected based on the hardware configuration.
If ATI CrossFireX is not enabled, access the ATI Catalyst Control Center (please refer to Page 13). From
the ATI Catalyst Control Center, enter the CrossFireX menu and assure to select the Enable CrossFire
TM
check box (Figure 2).
Two CrossFire graphics cards of the same type.
(Example: GV-RX16P128P-RH)
Figure 2
