3.4 Fiber Port Module (FPM) Installation
The Magnum 4K-Series Fiber Switches are normally received from the factory
with all required FPM modules installed. There may be situations where FPM cards need
to be added or replaced. In cases where additional FPM cards are needed, the face plate
for an available front-mounted slot must be removed. The following procedure describes
this operation.
3.4.1 Preparation for Installing and Removing FPMs
STOP!!!
Be sure the power cord is unplugged
from the chassis before attempting to remove
and/or replace any FPM cards.
Failure to do so may result in damage to the unit
and will void the warranty.
ARRÊT!!!!
Soyez sûr que le code de puissance
est débranché du châssis avant d'essayer au retirer
et/ou substitue toutes les cartes de FPM.
Le manque de faire ainsi le résultat dans les
dommages à l'unité et videra la garantie.
Caution- Avoid Static Discharge: The Fiber port modules (like most electronic
equipment) are sensitive to static discharge. Use proper ESD measures
when handling port modules.
L'Attention Évitent La Décharge Statique: Les modules de port de fibre
(comme la plupart de matériel électronique) sont sensibles à la
décharge statique. Utilisez les mesures appropriées d'cEsd en
manipulant les modules gauches.
Step 1. Make sure the FPM Card package has all necessary accessories to install it
properly. The FPM Card package for field installation comes along with a FPM
Card, enclosed with the Fiber Port Module Insertion guide.
NOTE: Please read the Port Module Insertion guide and 4K8 Manual
thoroughly before doing any field installation of FPM card.
