Machine data sheet
The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2
Model G1037Z
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G1037Z 13" PLANER/MOULDER
Product Dimensions:
Weight.............................................................................................................................................................. 217 lbs.
Length/Width/Height................................................................................................................. 23-1/2 x 23 x 44-1/2 in.
Foot Print (Length/Width)................................................................................................................. 22-1/4 x 21-1/4 in.
Shipping Dimensions:
Type............................................................................................................................................................. Cardboard
Content............................................................................................................................................................ Machine
Weight.............................................................................................................................................................. 240 lbs.
Length/Width/Height............................................................................................................................. 34 x 20 x 23 in.
Electrical:
Switch............................................................................................................................................ Push Button On/Off
Switch Voltage...................................................................................................................................................... 110V
Cord Length............................................................................................................................................................ 5 ft.
Cord Gauge....................................................................................................................................................14 gauge
Minimum Circuit Size........................................................................................................................................ 20 amp
Plug Included.......................................................................................................................................................... Yes
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower...........................................................................................................................................1-1/2 HP
Voltage.................................................................................................................................................110/220V
Prewired......................................................................................................................................................110V
Phase........................................................................................................................................................ Single
Amps..........................................................................................................................................................18/9A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ....................................................................................................................... Twin V-Belt Drive
Bearings....................................................................................................................... Shielded and Lubricated
Main Specifications:
Operation Info
Max. Cut Width...........................................................................................................................................13 in.
Max. Cut Height............................................................................................................................................6 in.
Min. Stock Length......................................................................................................................................12 in.
Min. Stock Width....................................................................................................................................... 3/8 in.
Max. Stock Thickness.................................................................................................................................. 6 in.
No. Of Cuts Per Inch............................................................................................................................... 52, 104
No. Of Cuts Per Minute............................................................................................................................. 15000
Cutterhead Speed.............................................................................................................................. 5000 RPM
Planing Feed Rate..................................................................................................................................24 FPM
Moulding Feed Rate............................................................................................................................... 12 FPM
Max. Cut Depth Planing Full Width......................................................................................................... 1/16 in.
Max. Cut Depth Planing 6 Inch Wide Board..............................................................................................1/8 in.
Max. Profile Depth Moulding..................................................................................................................... 3/4 in.
Max. Profile Width Moulding................................................................................................................ 4-9/16 in.
