H7946 parts list – Grizzly H7945 User Manual
Page 19
H7945/H7946/H7995 26° Angle Nailer
-17
-
H7946 PARTS LIST
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
1
PFH43M
FLAT HD SCR M6-1 X 10
47
PH7945047 MAGAZINE COVER
2
PH7945002 EXHAUST COVER
48
PH7945048 NAILER GUIDE
3
PSB53M
CAP SCREW M5-.8 X 18
49
PSB33M
CAP SCREW M5-.8 X 12
4
PH7945004 CAP
50
PH7945050 CONTACT ARM
5
PH7945005 SEAL
51
PRP96M
ROLL PIN 2 X 8
6
PH7945006 SPRING
52
PH7945052 SUPPORT PLATE
8
PH7945008 O-RING
53
PH7945053 O-RING
9
PH7945009 PISTON HEAD VALVE
56
PH7945056 CONTACT TRIP BLOCK
10
PH7945010 O-RING
57
PH7945057 ADJUSTING NUT
11
PH7945011 SEAL
58
PH7945058 ADJUSTING BOLT
12
PH7945012 O-RING
59
PH7945059 SPRING
13
PH7946013 PISTON
60
PH7945060 TRIP GUIDE
16
PH7946016 DRIVER
61
PH7945061 TRIGGER
17
PH7945017 COLLAR
62
PRP98M
ROLL PIN 3 X 16
18
PH7945018 CYLINDER
63
PH7945063 TRIGGER PLATE
19
PH7945019 O-RING
64
PH7945064 PLUNGER CAP
20
PH7945020 BUMPER
65
PH7945065 O-RING
21
PH7946021 SET PLATE
66
PH7945066 PLUNGER
22
PH7945022 GASKET
67
PH7945067 O-RING
23
PH7945023 NAILER BODY
68
PH7945068 SPRING
24
PH7945024 RUBBER GRIP
69
PH7945069 TRIGGER HEAD VALVE
25
PLN02M
LOCK NUT M5-,8
70
PH7945070 O-RING
29
PH7945029 STEPPED PIN
71
PRP97M
ROLL PIN 3 X 30
30
PH7945030 PUSHER GUIDE
72
PRP42M
ROLL PIN 3 X 20
31
PH7945031 O-RING
73
PH7945073 SLIDE SHAFT
32
PH7945032 ROLLER
75
PH7945075 O-RING
33
PFH27M
FLAT HD SCR M4-.7 X 5
76
PH7945076 O-RING
34
PH7945034 SPIRAL SPRING
77
PH7945077 O-RING
35
PH7946035 PUSHER
80
PH7945080 RUBBER LABEL
36
PSB139M
CAP SCREW M5-.8 X 22
81
PH7945081 COVER SET PLATE
37
PSB17M
CAP SCREW M4-.7 X 10
82
PH7945082 EXHAUST FILTER
38
PH7945038 NOSE COVER
83
PH7945083 SPACER
39
PSB18M
CAP SCREW M4-.7 X 8
84
PH7945084 SPACER
40
PH7946040 DRIVER GUIDE PLATE
85
PH7946085 NAILER CASE
41
PH7945041 NOSE
86
PH7945086 PNEUMATIC OIL
42
PH7945042 SPRING
87
PH7946087 NAIL ASSORTMENT
43
PH7946043 CORE TRIP
88
PAW03M
HEX WRENCH 3MM
44
PSBS24M
BUTTON HD CAP SCR M4-.7 X 10
89
PAW04M
HEX WRENCH 4MM
45
PH7945045 RUBBER PAD
90
PH7946090 PISTON REPAIR KIT
46
PH7946046 MAGAZINE
91
PH7946091 MACHINE LABEL
