GTO SL-1000 User Manual
Page 16
13
R
ECOMMENDED
W
IRING
AND
U
SE
OF
C
ONDUIT
CAUTION
AUTOMATIC GATE
STAND CLEAR
1-800-543-GATE
®
Separate PVC Conduits
for power, receiver
and control wiring.
Roller Guard
Roller Guard
Operator
Conduit through the concrete pad.
Roller Guard
Separate PVC Cond
for power, receiver
and control wiring.
Roller Guard
Roller Guard
Roller Guard
Conduit around the concrete pad.
CAUTION
AUTOMATIC GATE
STAND CLEAR
1-800-543-GATE
®
Operator
Run the low voltage wire and receiver wire through PVC conduit into the slider unit to protect it from lawn mowers,
weed eaters, grazing animals, etc. PVC conduit should be used for accessory wires such as loop detectors, key pads,
card readers or any other entry device.
WARN
ING
W
AR
N
IN
G
3/8"-16x3" Carriage Bolts
3/8" Lock Washers
& Nuts
48" x 2" sq. Legs
M
OUNTING
T
HE
L
EGS
ON
THE
S
LIDE
G
ATE
O
PERATOR
S
TEP
1
Mount the legs on the slide gate operator using
the
3
/
8
” x 3” Carriage Bolts,
3
/
8
” Flat Washers,
3
/
8
” Lock Washers, and
3
/
8
” Nuts. See
Illustration A.
Illustration A
