G0640X 17" Wood/Metal Bandsaw
-55-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0640X001 BUSHING 52 P0640X052 ADJUSTABLE RESISTOR
2 PSS01M SET SCREW M6-1 X 10 53 P0640X053 PLASTIC PIECE
3 P0640X003 BUSHING 54 P0640X054 KEY SWITCH
4 P0640X004 LIFTING EYE BOLT 55 P0640X055 UPPER WHEEL COVER
5 P0640X005 MACHINE BODY 56 PB10M HEX BOLT M6-1 X 25
6 PSS26M SET SCREW M5-.8 X 6 57 PW03M FLAT WASHER 6MM
7 P0640X007 BUSHING 58 P0640X058 BRUSH
8 PW05M FLAT WASHER 4MM 59 PSB06M CAP SCREW M6-1 X 25
9 P0640X009 POWER CORD 14AWG 60 P0640X060 KNOB
10 PN01M HEX NUT M6-1 61 PLN03M LOCK NUT M6-1
11 P0640X011 POINTER 62 P0640X062 STRAIN RELIEF 16MM
12 P0640X012 STEP SCREW M4-.7 x 6 63 P0640X063 HEIGHT POINTER
13 P0640X013 UPPER SHAFT 64 PN03M HEX NUT M8-1.25
14 PRP91M ROLL PIN 5 X 35 65 PB45M HEX BOLT M8-1.25 X 100
15 P0640X015 UPPER WHEEL SHAFT HINGE 66 P0640X066 KNOB SCREW M10-1.5 X 20
16 P0640X016 UPPER WHEEL SHAFT 67 P0640X067 KNOB SCREW M10-1.5 X 55
17 P0640X017 BUSHING 68 P0640X068 LOCATE HANDLE M10-1.5
18 P6205 BALL BEARING 6205ZZ 69 P0640X069 CAM
19 P0640X019 UPPER WHEEL 17" 70 P0640X070 LOCATE BLOCK
20 PR25M INT RETAINING RING 47MM 71 P0640X071 KNOB
21 PW01M FLAT WASHER 8MM 72 P0640X072 LEVER ROD
22 PSB11M CAP SCREW M8-1.25 X 16 73 PN09M HEX NUT M12-1.75
23 P0640X023 SAW BLADE 131-1/2" X 1/2" 74 P0640X074 SHAFT
24 PLW04M LOCK WASHER 8MM 75 PSBS22M BUTTON HD CAP SCR M8-1.25 X 20
25 PSB14M CAP SCREW M8-1.25 X 20 76 PLW04M LOCK WASHER 8MM
26 P0640X026 TIRE 77 P0640X077 PCB POWER CORD
27 P0640X027 LOWER WHEEL 17" 78 P0640X078 COVER
28 P0640X028 IDLE PULLEY 79 PSS09M SET SCREW M8-1.25 X 20
29 PN32 HEX NUT 1"-14 80 PN03M HEX NUT M8-1.25
30 PLW09 LOCK WASHER 1" 81 P0640X081 LOWER WHEEL SHAFT
31 P0640X031 MOTOR CORD 3 WIRE 82 P0640X082 MOTOR 1.5 HP 3PH
32 P0640X032 COMPRESSION SPRING 82-1 P0640X082-1 FAN COVER
33 PRP02M ROLL PIN 3 X 16 82-2 P0640X082-2 FAN
34 P0640X034 LOCATE BLOCK 82-3 P0640X082-3 ELECTRICAL BOX COVER
35 P51201 THRUST BEARING 51201 83 PB32M HEX BOLT M10-1.5 X 25
36 P0640X036 SWITCH 84 PLW06M LOCK WASHER 10MM
37 P0640X037 HANDWHEEL 85 P0640X085 MOTOR BRACKET
38 P0640X038 ADJUSTING BOLT 86 PSBS22M BUTTON HD CAP SCR M8-1.25 X 20
39 PFS07M FLANGE SCREW M5-.8 X 10 87 P0640X087 PLATE
40 PTLW02M EXT TOOTH WASHER 5MM 88 PFS07M FLANGE SCREW M5-.8 X 10
41 PN06M HEX NUT M5-.8 89 P0640X089 LOCATE BLOCK
42 PFS08M FLANGE SCREW M5-.8 X 16 90 PK15M KEY 5 X 5 X 35
43 P0640X043 SWITCH PLATE 91 PB81M HEX BOLT M8-1.25 X 20 (LH)
44 PSB11M CAP SCREW M8-1.25 X 16 92 P0640X092 MOTOR PULLEY
45 PW01M FLAT WASHER 8MM 93 PVA44 V-BELT A-44 4L440
46 P0640X046 UPPER WHEEL SLIDING BRACKET 94 PSB04M CAP SCREW M6-1 X 10
47 PSB06M CAP SCREW M6-1 X 25 95 P0640X095 LOWER WHEEL COVER
48 P0640X048 RIVET 3.2 X 10 96 PFH31M FLAT HD SCR M4-.7 X 8
49 PSB04M CAP SCREW M6-1 X 10 97 PW01M FLAT WASHER 8MM
50 P0640X050 PLASTIC WINDOW 98 P0640X098 METAL SAW BLADE 131-1/2" X 1/2"
51 P0640X051 VS SWITCH 99 PS12M PHLP HD SCR M3-.5 X 6
Parts List
