4.1.40. System Control Commands Containing Parameters: Pommel or pulse zone(s Toggle zone)
// Client side Map Descriptors
Map_Descriptors
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, GRAFIK_command, DA_Lut_List, DA_Lut_List_Offset, DA_Lut_Parms, DA_Lut_Parms_Offset, Length
Pulse_zone, Lut_triggers, 23, awt, LUT_GRF6_0, pulse_zone, Zone_list, 0, Zone_pars, 0, 1
DA_Lut_List setup
Position from DA_Lut_List_Offset
Description
0-63 Zone(s) to pommel or pulse
DA_Lut_Parms setup
Position from DA_Lut_Parms_Offset
Description
0 Delay1 cycles
1 Intensity1 ( 0-127 )
2 Fade1 cycles
3 Delay2 cycles
4 Intensity2 ( 0-127 or 255 )
5 Fade2 cycles
