FS-8700-84_Lutron_eLumen Driver Manual Page 17 of 36
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]
4.1.17. System Control Commands containing no Parameters: – Halt Zone
// Client side Map Descriptors
Map_Descriptors
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, GRAFIK_command, DA_Lut_List, DA_Lut_List_Offset, Length
Zone_halt, Lut_triggers, 0, awt, LUT_GRF6_0, halt_zone, Zone_list, 0, 1
DA_Lut_List data setup
Position from DA_Lut_List_Offset
Description
0-63 Zone(s) to halt
Note: After setting up the zone numbers to halt in the DA_Lut_List Data Array, trigger this command by writing the number of zones to halt into the
Data Array specified by Data_Array_Name at an offset specified by Data_Array_Offset.
4.1.18. System Control Commands containing no Parameters: – Stop Scene Ramp Up
// Client side Map Descriptors
Map_Descriptors
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, GRAFIK_command, DA_Lut_List, DA_Lut_List_Offset, Length
Stop_scn_rmp_up, Lut_triggers, 1, awt, LUT_GRF6_0, stop_scene_ramp_up, Area_list, 0, 1
DA_Lut_List data setup
Position from DA_Lut_List_Offset
Description
0-31 Area(s) with scenes to stop ramp up
Note: After setting up the area numbers to stop scene ramps in the DA_Lut_List Data Array, trigger this command by writing the number of areas
into the Data Array specified by Data_Array_Name at an offset specified by Data_Array_Offset.
