Antenna unit, Display unit rdp-120 – Furuno FR-1710 User Manual
Page 9
vii
FR-1710/1725
Ship’s Mains
24/32 VDC
or
100/110/115/220/230 VAC,
1
φ
, 50/60 Hz
ANTENNA UNIT
*: FR-1725 only
FR-1710
XN12AF-RSB0074-062 (24 rpm)
XN20AF-RSB0074-062 (24 rpm)
XN12AF-RSB0075-062 (42 rpm)
XN20AF-RSB0075-062 (42 rpm)
FR-1725
XN20AF-RSB0074-063 (24 rpm)
XN24AF-RSB0074-063 (24 rpm)
XN20AF-RSB0075-063 (42 rpm)
XN24AF-RSB0075-063 (42 rpm)
DISPLAY UNIT
RDP-120
ATA Board
ARP-17
GPS, etc.
Serial Data
(I/O)
Pulse Input
Speed Log
Gyrocompass
Gyro Converter
GC-8A
Option
Rectifier
RU-3424
External
Buzzer
OP03-21
Remote Display
FMD-8010/FMD-811
Video Plotter
RP-17 Board
Water temperature,
water depth
*
Note: The display unit is available
in AC or DC specification.
