Fr-1760ds scanner unit (con't), Fr-1760ds scanner unit (con’t) – Furuno FR-1710 User Manual
Page 68
4-4
FR-1760DS Scanner Unit (con’t)
Scanner motor
B801
PULSE GENERATOR
Board [A] MP-3795
Fan motor
B802
Magnetron
MG5240F
Figure 4-7 Scanner unit, right side view, RF section removed
MD Board
03P6668
CR813
CR814
CR815
Pulse transformer
T801
MAG HTR DET Board
[A] 03P6827
J821
Choke coil
L801
Relay
K801
K802
K803
PFN Board
[C]03P6669
Figure 4-8 RF section, rear view
