FS-8700-59 Canatal Driver Manual Page 8 of 19
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
5.2 Client Side Node Descriptor Parameters
Section Title
Nodes
Column Title
Function Legal Values
Node_Name Provide name for Node
Up to 32
alphanumeric
characters
Node_ID Address of physical server node (Canatal device address) 1-63
Protocol Specify protocol used Canatal, Satchnet
Port
Specify which port the device is connected to the
FieldServer
P1-P8, R1-R2 3
Cana_Node_Protocol_Type*
Specify which specific protocol is supported by the
Canatal device.
Series 2, 3, 4 and 5 support only “Network”.
Series 6, 8 and 9 support both “Network” and “Net2”.
Specifying this as Net2 will significantly improve
communication.
Network, Net2
Example
// Client Side Nodes
Nodes
Node_Name Node_ID , Protocol , Port , Cana_Node_Protocol_Type
Conditioner1 1
, Canatal , R1 , Net2
3 Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.
