Appendix A. Useful Features
Appendix A.1. Retrieving Data from Tables with Mixed Data Formats
The driver uses the Data Format listed in Appendix C.1 as the default. If this format is used to store all the data, unexpected results will occur. Read the Canatal product
literature, to determine the table storage format of the point(s) of interest and over-ride the default format using the Cana_Format Parameter.
A separate Map Descriptor is required to poll data of each Data Type where mixed formats are stored in a table.
Appendix A.1.1. Map Descriptor Example .
In this example two Map Descriptors are provided. They both read table 5 of a series 9 device. The default format used by the Driver is Byte, but the data is stored in
mixed formats. Thus it is necessary to consult the Canatal literature to determine the format of the required data and specify the Cana_Format keyword to override the
default data format. Refer to Appendix C.1
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name , Address , Length , Cana_Series , Cana_Table Scan_Interval Cana_Format
TABLE05_1 , TBL05_DATA , 0 , Rdbc , DEV11 , 1 , 7 , 9 , 5 , 1.0s , -
TABLE05_2 , TBL05_DATA , 0 , Rdbc , DEV11 ,, 10 , 1 , 9 , 5 , 1.0s , Swap_Int
This parameter over-rides the default data
type. According to the product specification
the Boiler Limit Time is stored as a Swapped
Integer
With the offset equal to zero the data is
placed in the array element equal to the
address. The offset is added to the address
when determining the element of the data
array to be used for storage.
This is the offset of the Boiler
Limit Time in Table 5.
Reads elements 1 through 7 from table 5 in a series 9 device. According to
the product specification the 8th element is stored using a different format
and thus using this Map Descriptor to read mixed data type will produce
unexpected results.
