7
E
J7825pr-0920
• Plug the charger into a standard wall outlet.
Note: If power flow to the wall outlet is controlled by a switch, make sure
the switch is ON.
•
Before first time use, charge the battery for at least 18 hours.
Never charge the battery longer than 30 hours.
• Recharge the battery after each use of your vehicle for at least
14 hours. Do not charge the battery longer than 30 hours.
• Once the battery is charged, disconnect the charger connector
from the battery connector. Unplug the charger from the wall outlet.
The battery is now ready to be installed in your vehicle. Please see
“Battery Installation” on page 11 for detailed instructions on installing
your battery. If your battery is already installed in your vehicle,
simply re-connect the battery connector and motor connector and
replace the battery retainer.
BATTERY CHARGING
IMPORTANT! The battery must be removed from your vehicle for
the initial charge in order to complete assembly. After assembly is
complete, you do not need to remove the battery from your vehicle
to recharge it.
• Plug the battery connector into the charger connector.
3
Charger
Connector
4
Battery
Connector
• Locate the lock fastener in the back end of the seat.
• Using a slotted screwdriver, turn the lock fastener 1/4 turn to the
unlocked position .
• Lift the seat from the vehicle.
Lock
Fastener
Seat
• Loosen the screw in the battery retainer and remove it.
• Lift the battery retainer and remove the battery from the bat-
tery compartment.
Battery
Compartment
Battery
Battery
Retainer
Unlocked
2
1
