Installation Requirements
4-6 C141-E230
(7) Service clearance area
The service clearance area, or the sides which must allow access to the HDDs for installation or
maintenance, is shown in Figure 4.6.
[Surface Y]
• Interface connection
[Surface Z]
• Holes for mounting screw
[Surface X]
• Holes for mounting screw
(Both Side)
Figure 4.6 Service clearance area
(8)
Environmental magnetic field
Do not install the HDDs in the vicinity of equipment giving off strong magnetic fields, such as
monitors, televisions, or loudspeakers.
(9)
Leakage magnetic flux
Do not mount the HDDs near the devices that the leakage magnetic flux influence easily.
