Depending on the conditions of use, installation and environment,
please be sure to make the appropriate settings and adjustments.
If you need help with installation and/or settings, please consult your
dealer.

CONTENTS

INFORMATION TO USER....................................................................... 2
PRECAUTIONS........................................................................................ 3
INSTALLATION....................................................................................... 4
SETTINGS ............................................................................................... 6
ADJUSTMENT ........................................................................................ 11
TROUBLESHOOTING ............................................................................. 12
SPECIFICATIONS .................................................................................... 13

ACCESSORIES

VDC-D1184VA

Hexagonal Wrench (Big)........................................................... 1 pc.

Hexagonal Wrench (Small) ....................................................... 1 pc.

Cushioning sheet...................................................................... 1 pc.

VDC-D2184VA

Hexagonal Wrench (Big)........................................................... 1 pc.

Cushioning sheet...................................................................... 1 pc.

FEATURES

The optical filter is switched automatically to color image or black
and white image according to the subject brightness.

Built-in interline transfer method 1/4" CCD, approx. 470,000
picture elements.

Equipped with a DSP (Digital Signal Processor).

Horizontal resolution, more than 520 TV lines.

High sensitivity, minimum required illumination is 0.06 lux (F1.4
B/W mode).

Two types of backlight compensation functions (multi-spot
photometry and center-focus photometry.)

Dual power supply 12 – 15 V DC or 24 V AC.

L5AK4/US, L5AL4/US GB 2003, 6, 6

English

1
