Friedrich MS24Y3F - Manual (Page 27)

1
1
2
1
1
1
4
4
1
1
4
2
6
1
1
1
1
Q'ty
INDOOR UNIT
Name and Shape Part No. Application
For positioning the indoor unit.
For under ceiling type.
For suspending the indoor unit from
ceiling.
For suspending the indoor unit on
the wall.
For fixing the wall bracket.
For indoor side pipe joint.
(Large pipe)
For indoor side pipe joint.
(Small pipe)
Adhesive type 70 x 230
For fixing the drain hose
L 280 mm
9358536018
9358535011
0700009037
9359107002
9358596005
9358595008
313806339400
0700007125
9358597002
0700076107
9350716012
313209328104
312300787605
9359242000
9359225003
313806350303
Tapping screw ( 4 x 10)
Tapping screw ( 4 x 20)
Installation template
Hanger bracket (left)
Hanger bracket- (right)
Anchor bolt (M12)
Special nut
Spring washer
Wall bracket
Cosmetic Panel-L
Cosmetic Panel-R
Coupler heat insulator (large)
Coupler heat insulator (small)
For fixing the drain hose. Nylon fastener
Drain hose
Insulation (drain hose)
VT wire
ACCESSORIES
The following installation parts are furnished. Use them as required.
26 2006.05.29
