PARTS LIST
INDOOR UNIT
Ref.
Description
Part No.
69
Louver
9358561010
8-1
Air Filter
9358567029
34
Capacitor (Fan Motor)
9900270193
56
Sirocco Fan Assy
9385258006
67
Rubber (Vibration-proof)
9385102002
68
Cap, Plastic
9358563007
108
Base Assy
9359061021
109
Casing, Plastic
9358543009
124
Kit (Dew Proof Plate)
9372673010
126
Motor Fixing Table Assy
9358591000
127
Drain Hose Assy
9359242000
138
Kit (Separate Wall-A)
9372666012
146
Evaporator Assy
KB07
9362513036
160
Drain Pan Assy (Kit)
9372669013
164
Fan Motor Assy-IN
9601527053
173
Hanger Bracket-L
9358596005
174
Hanger Bracket-R
9358595008
184-1
Thermistor Spring-A
313728262708
187
Clamp No. 1219
313361271706
195
Clamp SKB-100
313361275805
196-1
Clamp SKB-3M
312300787605
223
Control Box
9358600023
234
Thermistor Assy-Room
9703299087
235
Thermistor Assy-Pipe
9900022020
240
Remote Control Unit
9371190051
236
Controller PCB Assy
9705914278
(K01AL-050SHSE-C1)
320
Flap (Upper)-G
9358539019
321
Flap (Lower)
9358541012
338
Motor Fixture
9358594001
361
Bushing
9357942001
361-2
Bushing-B, Plastic
9358554005
361-3
Bushing-C, Plastic
9358553008
365-1
Special Screw
9359092001
365-2
Special Screw
9359091004
381
Locking Spacer, KGLS-4S
313209391506
385
Indicator PCB Assy
9705798014
407
Motor Rod
9358560006
408
Louver Link
9358556009
416
Insulation (Panel)-A
9358574003
417
Insulation (Panel)-B
9358914007
418
Insulation (Flap Base)
9358572009
443
Arm Bracket
9359281009
439
Drain Pan Wire
9358598009
470
Separate Wall-B (Kit)
9373448013
472
Grille Support
9358602003
473
Filter Bracket
9358607008
488
Grill-G
9358533017
Ref.
Description
Part No.
983
Barrier
9360283009
24
2006.06.13
506
Louver Rod
9358559000
508
Cosmetic Panel-R
9358535011
509
Cosmetic Panel-L
9358536018
514
Control Box Cover
9359097006
520
Flap Base
9358537015
521
Louver Link Cover
9358558003
554
Flap Link-Upper (Step Motor-V)
9358551004
555
Flap Link-Lower (Step Motor-V)
9358552001
558
Motor Rod-A (Step Motor-V)
9358550007
577
Catch TL-119
9359096009
578
Base Bracket (Reinforcement)
9358586006
580
Top Cover
9358534014
581
Protector, Metal (Fan Motor)
9359282006
625
Cord Bushing KR-51
9359240006
628
Locking Spacer-B
313005446558
652-1
Thermistor Holder Pipe
313806262805
653-2
Bolt
0700190018
684
Motor Base
9358562000
731
Holder (Guide Rail)
0600241018
743
Remote Control Holder
9305642014
755
Casing Cover
9358544006
764
Drain Cap
9358746004
771
Panel
9358531136
735
800
Distributor Assy
9373034025
Bypass Pipe Assy
9373032021
815
Terminal 7P
9703403026
824
Fuse BET3.15A - 250V
0600239534
870-1
Arm
9358565001
876-1
Step Motor-H
9359106012
876-2
Step Motor
9900362010
982
Cord Clamp
9359183006
(K01AL-050PHSE-PO)
9704561343
875
Power Supply PCB Assy
502
Support Stay
9358599006
503
Louver Shaft
9358557006
505
Louver Stopper
9358555002
500
Protect Cover
9358564004
