Friedrich MS24Y3F - Manual (Page 26)

25 2006.05.25
OUTDOOR UNIT
1 Top Panel Sub Assy 9374417025
2 Front Panel 9374094066
3 Fan Guard 9374330010
4 Grip Side 9374173013
5 Service Panel Sub Assy 9374415038
6 Right Panel 9374095148
8 Propeller Fan Assy 9366378020
9 Motor, Induction 9602114016
10 Condenser-A Assy 9374433148
11 Coil Choke 9900366018
12 Strainer Assy 9372524015
13 Separate Wall Assy 9375226015
14 Cap Foot 9374345014
15 Base Assy 9374166183
17 3-Way Valve Assy (3/8) 9372205044
18 3-Way Valve Assy (5/8) 9372205075
19 Check Joint Assy 9372802038
20 Compressor Assy 9373711018
22 4-Way Valve 9900164010
23 Solenoid 9900165055
24 Pressure Switch 9900186012
25 Inlet Pipe Cond A Assy 9373461067
26 Inlet Pipe Cond B Assy 9373463054
27 Outlet Pipe Cond A Assy 9374266050
28 Expansion Valve Assy 9370947113
29 Coil (Expansion Valve) 9900057039
30 Distributor 9369128004
31 Discharge Pipe A Assy 9372264140
33 Terminal 2P 9701971015
34 Terminal 5P 9900203023
35 ACTPM 9703457012
36 Holder Thermo 9372797013
37 Inverter PCB Assy 9705642089
38 Power PCB Assy 9705647046
---- Heatsink Thermistor 9900311018
---- Arrester 0600280147
---- Transformer 9702334024
---- Thermistor 9900041014
---- Compressor Thermistor 9900156022
---- Thermistor (Discharge) 9704219114
---- Heat Exchanger Thermistor 9900374013
---- Thermistor (Outdoor Temp.) 9900378035
---- Varistor 0000361224
---- Switch Slide 9701392018
---- Switch Push 9703476013
---- Relay 9900007010
---- Relay 9900117016
---- Fuse 3.15A-250V 0600239534
---- Drain Pipe Assy 9303029015
---- Drain Cap 313166024302
Ref. Description Part No.
