8
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S
Drive1 Submenu of the Main Menu
The Drive1 submenu identifies which ATA/IDE devices are installed.
Figure 3. Drive1 Submenu
Menu Field Options Default Description
Type: ■ Auto
■ None
[Auto] NOTE: The Type field does not appear as a drop-down menu. Tap the
spacebar to toggle the selections.
Selects the ATA/ATAPI device type. Select Auto to have the type auto-
matically identified by the BIOS at POST. If None is selected, all of the fol-
lowing setup items do not appear.
Multi-Sector
Transfers: ■ Disabled
■ 2 Sectors
■ 4 Sectors
■ 8 Sectors
■ 16 Sectors
[Disabled] This option cannot be changed (automatically identified by the BIOS).
Specifies the number of sectors per block for multiple sector transfer.
LBA Mode Control: ■ Disabled
■ Enabled
[Disabled] Enables or disables Logical Block Addressing in place of Cylinder, Head,
Sector addressing. This option cannot be changed (automatically identi-
fied by the BIOS).
Transfer Mode: ■ Standard
■ Fast PIO 1
■ Fast PIO 2
■ Fast PIO 3
■ Fast PIO 4
■ Multiword DMA 1
■ Multiword DMA 2
Standard Selects the method for moving data to/from the drive. Autotype the drive
to select the optimum transfer mode. This option cannot be changed
(automatically identified by the BIOS). Multi-word DMA is automatically
set to mode 1 for Fast PIO 1, Fast PIO 2, Fast PIO 3, and set to mode 2
for Fast PIO 4 / DMA.
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space Change Values
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
▲
Main Advanced Security Power Boot Info Exit
Item Specific Help
Select Serial ATA/IDE
drive installed here.
[Auto]
The BIOS auto-types the
drive on boot time.
[None]
The drive is disabled.
Drive1 [MATSHITADVD-RAM UJ-832S]
Type: [ Auto] ]
Multi-Sector Transfers: [Disabled]
LBA Mode Control: [Disabled]
Transfer Mode: [Disabled]
Ultra DMA Mode: [Disabled]
