6
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S
Drive0 Submenu of the Main Menu
The Drive0 submenu identifies which ATA devices are
installed.
Figure 2. Drive0 Submenu
Table 2: Fields, Options and Defaults for the Drive0 Submenu of the Main Menu
Menu Field Options Default Description
Type: ■ Auto
■ None
[Auto] Select [Auto] to have the type of Serial or Parallel ATA device automatically
identified by the BIOS at POST. If [None] is selected, the following Set-up
items do not appear.
LBA Format Logical Block Addressing (LBA)
Total Sectors: --- --- The total number of sectors on your hard disk. This information is automati-
cally displayed when [Auto] is selected.
Maximum
Capacity: --- --- The maximum capacity of your hard disk. This information is automatically
displayed when [Auto] is selected as the Type.
Multi-Sector
Transfers: ■ Disabled
■ 2 Sectors
■ 4 Sectors
■ 8 Sectors
■ 16 Sectors
[16 Sectors] This information is automatically selected when [Auto] is selected as the Type.
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space Change Values
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
▲
Main Advanced Security Power Boot Info Exit
Item Specific Help
Select Serial ATA/IDE
drive installed here.
[Auto]
The BIOS auto-types the
drive on boot time.
[None]
The drive is disabled.
Drive0 [TOSHIBA MK6006GAH]
Type: [Auto]
LBA Format
Total Sectors: 117210240
Maximum Capacity: 60012MB
Multi-Sector Transfers: [16 Sectors]
LBA Mode Control: [Enabled]
Transfer Mode: [Multiword DMA 2]
Ultra DMA Mode: [Disabled]
