1 EQUIPMENT SET-UP
1.1 Supplied equipment
FS-X25 Series FieldServer.
loaded with Modbus RTU driver, SMT Ethernet driver and any other drivers ordered. A default
configuration file has already been loaded onto the FieldServer. Check the Driver Manual and the
FieldServer Configuration Manual for further information on this file.
USB Flash Drive loaded with:
FS-X25 Series Start-up Guide
FieldServer Configuration Manual
FieldServer Utilities Manual
All FieldServer Driver Manuals
Support Utilities
Any additional folders related to special files configured for a specific FieldServer
Additional components as required - See Driver Manual Supplement for details
Accessories:
7-ft Cat5 cable with RJ45 connectors at both ends (Part # FS-8915-10)
Power Supply
1.2 Mounting
The FS-X25 Series FieldServer is supplied with an accessory bag which allows selection of adhesive feet (for
standing on a shelf) or mounting plates for wall or panel mount. A DIN Rail Mounting Kit (P/N FS-8915-28) may be
ordered separately.
1.3 Wiring
5-30VDC must be connected to the terminal block
1.3.1 Compliance with UL Regulations
For UL compliance, the following instructions must be met when operating the FieldServer.
The units shall be powered by listed LPS or Class 2 power supply suited to the expected operating temperature
range.
The interconnecting power connector and power cable shall:
Comply with local electrical code.
Be suited to the expected operating temperature range.
Meet the current and voltage rating for the FieldServer/Net
Furthermore, the interconnecting power cable shall:
Be of length not exceeding 3.05m (118.3”)
Be constructed of materials rated VW-1 or FT-1 or better.
If the unit is to be installed in an operating environment with a temperature above 65 °C, it should be installed
in a Restricted Access Area requiring a key or a special tool to gain access
This device must not be connected to a LAN segment with outdoor wiring.
