2.3 Setting Up the Receiver
page 10 Document no. 93-005-35-C5
2.3 Setting Up the Receiver
1. Place the
7870R
Receiver in any of the 7180M Chassis, unless a
2040 RF Switch is installed. (See
Figure 7 7180M Chassis Rear View
on page 12.)
Note
If a 2040 RF Switch(es) is being installed, then slots 2 and/or 5
of the 7180M are reserved for the switch(es).
2. Apply AC power to the chassis. The Power Supply’s LED should
be lit.
3. Using an optical power meter, measure the optical power coming
to the Receiver from the fiber optic cable. The power levels of the
Receiver should be the power level measured at the Transmitter
minus the fiber loss
2 .
Alternatively, use a DVM to measure the voltage at:
• pins J13-P9 through J13-P16 for the slot being measured (See
Table 5 7870R Receiver Pinout
on page 21 for details regarding J13
pinouts) (7180M Rackmount). The voltage level should be 1 V
for each 1 mW measured at the Receiver input.
• at pin #5 of the 9 pin connector (standalone)
4. On the rear panel, connect the coax cable to the RF Output
Connector.
5. Adjust the Gain Control Potentiometer to give the desired output
power. Using a small screw driver, turn the potentiometer
(located on the front panel) to increase or decrease the gain.
Notes
1. The potentiometer is 10 turn potentiometer.
• To
increase
the gain, turn the gain control clockwise.
• To
decrease
the gain, turn the gain control counterclockwise.
For more information see
2.6 Aligning the Fiber Optic Link
on page15.
2. If the LED is not lit, see
Chapter 4 Troubleshooting
on page 25.
2. Fiber loss is defined as:
(attenuation/km x length (km) of the fiber optic cable) + (0.5 dB ×
number of connectors).
For example if a signal with an optical wavelength of 1310 nm is
transmitted over a link 10 kilometers long which had two connectors
the loss would be:
(0.4 dB/km × 10 km) + (0.5 dB × 2) = 5.0 dB
