7 7
17
Upper
Posts
ASSEMBLY ASSEMBLY
• Turn the backboard over.
• Fit the upper posts onto the backboard.
Hint: The upper posts only assemble to the backboard one way.
If an upper post does not seem to fit on one side of the backboard,
try the other side!
• Insert three #8 x 3 /
4
” screws into each upper post and tighten.
18
• Pull the rim down, as shown.
• Snap the rim into the backboard as shown.
Hint: The rim can only be assembled one way. If it does not seem
to fit, turn it around and try again!
15
Rim
16
• Wipe the backboard with a soft cloth.
• Carefully peel a label from the label sheet and apply it to the
backboard as shown. Smooth out the label to remove any
air bubbles.
• Repeat this procedure to apply the remaining labels to
the backboard.
Hint: These labels are designed to overlap!
14 1
2
3
4
Backboard
