• Lift the side tubes up to fit them into the hole in each
base assembly.
Hint: The top of the net will flop forward.
• Slide a side tube, straight end first, through the sleeve on each
side of the net.
Sleeve
Side Tube
Sleeve
Side Tube
ASSEMBLY ASSEMBLY
4
5
6
• Fit the upper end of the side tubes into the groove in each post.
Post
Grooves
Side Tubes
• Note the numbers on the base covers.
• Fit the base cover labeled
1 onto the base assembly labeled 1 .
Hint: Make sure the net is not under the base cover.
• Insert four #8 x 3 /
4
” screws into the base cover and tighten.
• Repeat this procedure to attach the other base cover labeled
2 to the base assembly labeled 2 .
7
1
Base Covers
2
